Description
NEC MultiSync® EA234WMi
features an extremely thin LED backlight panel with IPS technology which results in an ultra-modern and slim design in combination with a premium feature set for the corporate office use. Ambient Light and Human Sensors enforce the sustainable product concept while offering improved ergonomics with 130 mm height adjustability. Moreover the display offers broad connectivity with four inputs DisplayPort, HDMI , DVI-D and D-Sub. Thanks to its excellent IPS image quality with wide viewing angles in 16:9 screen format, it offers a high level of ergonomic comfort.
Ideal for the corporate that demands style and future proof technology.
– Ambient Light Sensor – with Auto Brightness function always sets optimised brightness level according to ambient light and content conditions.
– Feature Set for Perfect Office Use – Integrated Speakers, headphone jack and USB Hub provide excellent options for office communication.
– Ergonomic Office – full height adjustability (130 mm), swivel, tilt and pivot functionality ensures perfect individual ergonomic set-up.
– Human Sensor – detects the presence of a person in front of the screen; display switches on/off automatically depending on the presence of the user.
– Vesa Mount (100 mm) – allows to install the monitor via various mounting solutions.
– NaViSet Compatible – for comprehensive network-wide asset management and easier remote support.
– DICOM Simulation – for straightforward radiological review applications.
– Free Download of Multi-Display Management Software – with NaViSet Administrator 2 you can manage all your connected display devices from a centralized location.
– Special Characteristics – Ambient light sensor for optimized brightness levels; Carbon Footprint Meter ; Carbon Savings Meter ; ControlSync® ; Customize Setting ; DICOM Simulation ; EcoModes ; Energy Star 6.0; ErgoDesign® : Height adjustable stand (130 mm) with 90° Pivot features; Human Sensor; LED Backlight Technology; NaViSet Administrator 2; NaViSet®and NaViSet®Administrator compatible; sRGB Support; Touch Sensor Keys; USB ver. 2.0 (4 down / 1 up); Windows 8 compatible
| Feature |
Feature Value |
| Display diagonal |
58.4 cm (23″) |
| Display resolution |
1920 x 1080 pixels |
| Native aspect ratio |
16:9 |
| Display technology |
LCD |
| Touchscreen |
No |
| HD type |
Full HD |
| Panel type |
TFT/IPS |
| Response time |
6 ms |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Maximum refresh rate |
60 Hz |
| Display number of colours |
16.78 million colours |
| Backlight type |
W-LED |
| Display brightness (typical) |
250 cd/m² |
| Supported graphics resolutions |
1280 x 960, 1400 x 900, 1680 x 1056, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Aspect ratio |
16:9 |
| Contrast ratio (dynamic) |
25000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.265 x 0.265 mm |
| Digital horizontal frequency |
31.5 – 83 kHz |
| Digital vertical frequency |
56 – 75 Hz |
| Colour gamut standard |
sRGB |
| 3D |
No |
| Windows operating systems supported |
Windows 8 |
| Built-in speaker(s) |
Yes |
| Built-in camera |
No |
| Number of speakers |
2 |
| RMS rated power |
2 W |
| Product colour |
White |
| Built-in USB hub |
Yes |
| Headphone out |
Yes |
| USB hub version |
2.0 |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
4 |
| VGA (D-Sub) ports quantity |
1 |
| DVI port |
Yes |
| DVI-D ports quantity |
1 |
| DVI-I ports quantity |
0 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Headphone outputs |
1 |
| HDCP |
Yes |
| Wi-Fi |
No |
| Bluetooth |
No |
| Ethernet LAN |
No |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Height adjustment |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Cable lock slot type |
Kensington |
| Adjustable height (max) |
13 cm |
| Pivot |
Yes |
| Pivot angle |
0 – 90° |
| Swivelling |
Yes |
| Swivel angle range |
-170 – 170° |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 – 30° |
| On Screen Display (OSD) |
Yes |
| Plug and Play |
Yes |
| LED indicators |
Power |
| Energy efficiency class (SDR) |
D |
| Energy consumption (SDR) per 1000 hours |
12 kWh |
| Power consumption (typical) |
22 W |
| Power consumption (max) |
27 W |
| Power consumption (PowerSave) |
0.5 W |
| Energy efficiency scale |
A to G |
| Operating temperature (T-T) |
5 – 35 °C |
| Operating relative humidity (H-H) |
20 – 80% |
| Width (with stand) |
543.8 mm |
| Depth (with stand) |
218 mm |
| Height (with stand) |
380.4 mm |
| Weight (with stand) |
6.4 kg |
| Width (without stand) |
543.8 mm |
| Cables included |
DisplayPort, USB |
| Quick start guide |
Yes |
| Sustainability certificates |
EPEAT Gold, ENERGY STAR |
| Display |
LED |
| On/off switch |
Yes |
| TV tuner integrated |
No |
| Power consumption (economy mode) |
16 W |
| ECO mode |
Yes |
| Light sensor |
Yes |
| Power management |
Yes |
| Certification |
CE; Energy Star 6.0; FCC Class B; ISO 9241-307 (pixel failure class I); MPR III; PCT/Gost; RoHS; TCO 6.0; TCO Certified Edge Displays 1.2.; TÜV Ergonomics; TÜV GS; UL/C-UL, CSA |
| Thin client installed |
No |
| Harmonized System (HS) code |
85285210 |
| European Product Registry for Energy Labelling (EPREL) code |
392064 |
