Description
Powering workspace communications
Powering your PC/notebook and all your devices through a single cable, the MultiSync® EA242F is your workspace hub; no docking station required, the 65W USB-C connection means an efficient, clutter-free workstation from which to manage your communications. Easily increase your display area using DisplayPort-out to daisy-chain multiple displays, no additional cabling required.
User comfort is fundamental with full height adjustment, tilt, pivot and swivel supporting customised personal setup, whilst built-in low blue light technologies guard against eye fatigue without compromising true-to-life colour performance. Available in black or white, the 24” EA242F complements office interior design and ergonomics.
The connectivity advantage continues beyond USB Type-C with DisplayPort, HDMI, VGA and USB A for fully future-proof flexibility supporting new open office standards in hot desking and ‘bring your own device.’
| Feature |
Feature Value |
| Display diagonal |
60.5 cm (23.8″) |
| Display resolution |
1920 x 1080 pixels |
| Native aspect ratio |
16:9 |
| Display technology |
LED |
| Touchscreen |
No |
| HD type |
Full HD |
| Panel type |
TFT/IPS |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Maximum refresh rate |
60 Hz |
| Display number of colours |
16.78 million colours |
| Backlight type |
W-LED |
| Display brightness (typical) |
250 cd/m² |
| Response time |
5 ms |
| Aspect ratio |
16:9 |
| Contrast ratio (dynamic) |
5000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.275 x 0.275 mm |
| Digital horizontal frequency |
31.5 – 83 kHz |
| Digital vertical frequency |
50 – 75 Hz |
| Display diagonal (metric) |
60.47 cm |
| DDC/CI |
Yes |
| Flicker-free technology |
Yes |
| Built-in speaker(s) |
Yes |
| Number of speakers |
2 |
| RMS rated power |
2 W |
| Product colour |
Black |
| Built-in USB hub |
Yes |
| HDMI |
Yes |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports |
1 |
| VGA (D-Sub) ports quantity |
1 |
| DVI port |
No |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
2 |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Height adjustment |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Cable lock slot type |
Kensington |
| Height adjustment |
15 cm |
| Swivelling |
Yes |
| Swivel angle range |
-170 – 170° |
| Tilt angle range |
-5 – 35° |
| Plug and Play |
Yes |
| Tilt adjustment |
Yes |
| Energy efficiency class (SDR) |
D |
| Energy consumption (SDR) per 1000 hours |
13 kWh |
| Power consumption (typical) |
21 W |
| Power consumption (PowerSave) |
0.3 W |
| AC input voltage |
100 – 240 V |
| Energy efficiency scale |
A to G |
| Operating temperature (T-T) |
5 – 35 °C |
| Storage temperature (T-T) |
-10 – 60 °C |
| Operating relative humidity (H-H) |
20 – 80% |
| Storage relative humidity (H-H) |
10 – 85% |
| Cables included |
AC, DisplayPort, USB |
| Width (with stand) |
615.4 mm |
| Depth (with stand) |
250 mm |
| Height (with stand) |
319.1 mm |
| Weight (with stand) |
7 kg |
| Bezel width (side) |
0.8 mm |
| Bezel width (top) |
0.8 mm |
| Bezel width (bottom) |
1.58 cm |
| Package type |
Box |
| Sustainability certificates |
CE, ENERGY STAR, ErP, RoHS |
| Harmonized System (HS) code |
85285210 |
| Energy efficiency class (old) |
A+ |
