Description
Primed for Office Productivity
Optimised for multi-display set ups, the ultra-narrow bezel NEC MultiSync EA242WU is designed to support maximum productivity in today’s hybrid workspaces. Daisy-chaining neighbouring displays, embedded LAN and USB-C connectivity all contribute to minimal cabling and maximum flexibility – the display becomes the hub of workspace communications!
Create individually tailored workspaces with best ergonomic adjustability and user-centred features including built-in low blue light and flicker-free technologies to protect the health of the viewers’ eyes and guard against fatigue, without compromising the high-performance IPS screen technology.
Fulfilling the demand for future-ready performance and delivering all the trusted quality and reliability of the Sharp/NEC brand, the EA242WU is purpose-designed to maximise office productivity.
| Feature |
Feature Value |
| Display diagonal |
61 cm (24″) |
| Display resolution |
1920 x 1200 pixels |
| Native aspect ratio |
16:10 |
| Display technology |
LCD |
| Touchscreen |
N |
| Panel type |
TFT/IPS |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Maximum refresh rate |
60 Hz |
| Display number of colours |
16.7 million colours |
| Backlight type |
W-LED |
| Display brightness (typical) |
300 cd/m² |
| Response time |
6 ms |
| Supported graphics resolutions |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768, 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900, 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
| Contrast ratio (dynamic) |
5000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.27 x 0.27 mm |
| Digital horizontal frequency |
31.5 – 77 kHz |
| Digital vertical frequency |
50 – 60 Hz |
| Display diagonal (metric) |
61 cm |
| Flicker-free technology |
Y |
| Low Blue Light technology |
Y |
| Built-in speaker(s) |
Y |
| Built-in camera |
N |
| Number of speakers |
2 |
| RMS rated power |
2 W |
| Product colour |
Black |
| Front bezel colour |
Black |
| Built-in USB hub |
Y |
| HDMI |
Y |
| Headphone out |
Y |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
2 |
| USB Power Delivery |
Y |
| USB Power Delivery up to |
65 W |
| DVI port |
N |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Wi-Fi |
N |
| Bluetooth |
N |
| Ethernet LAN |
Y |
| VESA mounting |
Y |
| Cable lock slot |
Y |
| Height adjustment |
Y |
| Panel mounting interface |
100 x 100 mm |
| Cable management |
Y |
| Cable lock slot type |
Kensington |
| Height adjustment |
15 cm |
| Pivot |
Y |
| Pivot angle |
-90 – 90° |
| Swivelling |
Y |
| Swivel angle range |
-170 – 170° |
| Tilt angle range |
-5 – 35° |
| On Screen Display (OSD) |
Y |
| Plug and Play |
Y |
| LED indicators |
Y |
| Tilt adjustment |
Y |
| Energy efficiency class (SDR) |
D |
| Energy consumption (SDR) per 1000 hours |
13 kWh |
| Power consumption (typical) |
21 W |
| Power consumption (PowerSave) |
0.3 W |
| Power supply type |
Internal |
| Energy efficiency scale |
A to G |
| Operating temperature (T-T) |
-5 – 35 °C |
| Operating relative humidity (H-H) |
20 – 80% |
| Stand included |
Y |
| Cables included |
AC, USB Type-C |
| Quick start guide |
Y |
| Width (with stand) |
531 mm |
| Depth (with stand) |
250 mm |
| Height (with stand) |
365 mm |
| Weight (with stand) |
6.7 kg |
| Bezel width (top) |
0.8 mm |
| Sustainability certificates |
CE, ENERGY STAR, TCO |
