Description
Uncompromising performance for highly demanding workflows
Where detail and precise visualisation is application-critical, the extensive 31” screen estate with true 4K resolution provides an outstanding canvas for viewing of vast content in highly demanding workplaces. Appealing for post-production workflows, the 4096 x 2160 resolution supports the processing of original footage without downscaling to UHD resolutions. With a High Dynamic Range, images appear sharper, more natural and true-to-life.
Supporting your creative output, the 31.5’’ panel, 14 bit gamma 3D look up table, SpectraView® Engine, integrated calibration sensor and support for an external sensor ensure superior colour reproduction and management processes. The USB Type C delivers 65W to charge power hungry notebooks and mobile devices directly from the display whilst delivering 4K signal in DP Alt mode with one single cable connection.
Demanding users in the creative industry from architects to media producers and C&C operators will appreciate the advanced innovation and outstanding ergonomics of the PA311D.
| Feature |
Feature Value |
| Display diagonal |
78.7 cm (31″) |
| Display resolution |
4096 x 2160 pixels |
| Native aspect ratio |
17:9 |
| Display technology |
LCD |
| Touchscreen |
No |
| HD type |
4K Ultra HD |
| Panel type |
IPS |
| Response time |
8 ms |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1400:1 |
| Maximum refresh rate |
60 Hz |
| Display number of colours |
1.073 billion colours |
| Backlight type |
W-LED |
| Display brightness (typical) |
350 cd/m² |
| Supported graphics resolutions |
640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2550 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160, 4096 x 2160 |
| Pixel pitch |
0.1704 x 0.1704 mm |
| Horizontal scan range |
15 – 135 kHz |
| Vertical scan range |
24 – 75 Hz |
| Viewable size, horizontal |
69.8 cm |
| Viewable size, vertical |
36.8 cm |
| 3D |
No |
| NVIDIA G-SYNC |
No |
| AMD FreeSync |
No |
| Flicker-free technology |
Yes |
| Low Blue Light technology |
Yes |
| Built-in speaker(s) |
Yes |
| Built-in camera |
No |
| Number of speakers |
2 |
| RMS rated power |
2 W |
| Market positioning |
Business |
| Product colour |
Black |
| Feet colour |
Black |
| Built-in USB hub |
Yes |
| HDMI |
Yes |
| USB hub version |
2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports |
3 |
| USB Type-A downstream ports quantity |
3 |
| USB Type-C downstream ports quantity |
1 |
| VGA (D-Sub) ports quantity |
0 |
| DVI port |
No |
| HDMI ports quantity |
2 |
| HDMI version |
2.0 |
| DisplayPorts quantity |
2 |
| Ethernet LAN |
Yes |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Height adjustment |
Yes |
| Panel mounting interface |
100 x 100,100 x 200 mm |
| Cable lock slot type |
Kensington |
| Adjustable height (max) |
15 cm |
| Swivelling |
Yes |
| Swivel angle range |
-45 – 45° |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 – 30° |
| Picture-in-Picture |
Yes |
| Plug and Play |
Yes |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
G |
| Energy consumption (SDR) per 1000 hours |
79 kWh |
| Energy consumption (HDR) per 1000 hours |
92 kWh |
| Power consumption (typical) |
84 W |
| Power consumption (standby) |
2 W |
| Power consumption (max) |
187 W |
| Power consumption (PowerSave) |
10 W |
| AC input frequency |
50 – 60 Hz |
| Input current |
1/2.4 A |
| Energy efficiency scale |
A to G |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-20 – 50 °C |
| Operating relative humidity (H-H) |
20 – 85% |
| Storage relative humidity (H-H) |
10 – 85% |
| Operating altitude |
0 – 5000 m |
| Non-operating altitude |
0 – 12192 m |
| Width (with stand) |
737.9 mm |
| Depth (with stand) |
301.6 mm |
| Height (with stand) |
433.2 mm |
| Weight (with stand) |
14.9 kg |
| Weight (without stand) |
8.6 kg |
| Bezel width (side) |
1.93 cm |
| Bezel width (top) |
2.21 cm |
| Bezel width (bottom) |
2.21 cm |
| Cables included |
AC, DisplayPort, DisplayPort to Mini DisplayPort, Mini DisplayPort, USB |
| On/off switch |
Yes |
| TV tuner integrated |
No |
| Picture-by-Picture (PbP) |
Yes |
| Compliance certificates |
RoHS |
| Ethernet LAN (RJ-45) ports |
1 |
| Certification |
CE; EAC; ErP; ISO 9241-307; TÜV GS; WEEE |
| European Product Registry for Energy Labelling (EPREL) code |
404828 |
