Description
Need to increase your business productivity and improve operations while balancing your employees’ mobility, security and collaboration needs, all within your limited IT budget? HPE ProLiant ML350 Gen9 Server delivers a class-leading combination of performance, expandability, manageability, reliability and serviceability making it the choice for enterprise data centers, expanding SMBs and remote offices of larger businesses. ML350 Gen9 Server leverages the Intel® Xeon® E5-2600 v3 and v4 processors with up to 21% 1 performance gain, plus the latest HPE DDR4 SmartMemory offering up to 23% 2 performance increase.
Additional support for 12 Gb/s SAS, embedded 4x1GbE NIC with a broad range of graphics and compute options. Manage your HPE ProLiant Server in any IT environments by automating the most essential server lifecycle management tasks: deploy, update, monitor, and maintain with ease.
The ML350 Gen9 Server is ideal for enterprise IT infrastructure to mission critical applications.
Features
Performance with Unmatched Capacity and Reliability
– The HPE ProLiant ML350 Gen9 Server supports up to two Intel® Xeon® E5-2600 v3 or v4 processors offering improved performance.
– HPE Smart Array Controllers are designed to increase 12 Gb/s performance, data availability and storage capacity while providing the flexibility in choice of solutions that are simple to manage.
– Up to (24) DIMM slots to support HPE DDR4 SmartMemory 2400MHz, helping to prevent data loss and downtime with enhanced error handling while improving workload performance and power efficiency.
Availability, Expandability and Serviceability – A Winning Combination
– The HPE ProLiant ML350 Gen9 Server offers expandability with greater capacity with (8) to (24) LFF, (8) to (48) SFF drive options and increased I/O expansion.
– Large expansion capacity with (9) PCIe expansion slots, (8) USB ports, 5U Rack conversion, and Power Supply options.
– Embedded 4x1Gbe and choice of HPE PCIe standup 1GbE or 10GbE Adapters provide you flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.
– Wider GPU support (4) to boost performance in graphic and VDI applications for financial services, education, scientific research, and medical imaging.
– Worldwide availability, service and support with a complete range of Foundation Care offerings from installation to extended support.
Agile Infrastructure Management for Essential Administration
– The HPE ProLiant ML350 Gen9 Server provides powerful converged management capabilities for the infrastructure lifecycle with embedded server management for provisioning, updating and diagnostic support with HPE iLO.
– Configure in Unified Extensible Firmware Interface (UEFI) boot mode to provision local and remote servers with Intelligent Provisioning and Scripting Toolkits.
– Online personalized dashboard for converged infrastructure health monitoring and support management with HPE Insight Online.
– Optimize firmware and driver updates and reduce downtime with Smart Update, consisting of Smart Update Manager (SUM) and Service Pack for ProLiant (SPP).
Energy Efficiency by Design
– The HPE ProLiant ML350 Gen9 Server offers ENERGY STAR® qualified server configurations illustrate the HPE continued commitment to helping customers conserve energy and save money.
– Next generation high efficiency redundant HPE Flexible Slot Power Supplies provide up to 94% efficiency (Platinum Plus) and support for HPE’s Power Discovery Services.
– Improved ambient temperature standard with ASHRAE A3 and A4 3 helps you reduce cooling costs.
| Feature |
Feature Value |
| Processor family |
Intel® Xeon® E5 v4 |
| Processor manufacturer |
Intel |
| Processor model |
E5-2630V4 |
| Processor frequency |
2.2 GHz |
| Processor boost frequency |
3.1 GHz |
| Processor cores |
10 |
| Processor cache |
25 MB |
| Motherboard chipset |
Intel C610 |
| Memory channels supported by processor |
Quad |
| Number of processors installed |
2 |
| Thermal Design Power (TDP) |
85 W |
| Processor cache type |
Smart Cache |
| System bus rate |
8 GT/s |
| Maximum number of SMP processors |
2 |
| Processor socket |
LGA 2011-v3 |
| Processor lithography |
14 nm |
| Processor threads |
20 |
| Processor operating modes |
64-bit |
| Stepping |
R0 |
| Bus type |
QPI |
| Number of QPI links |
2 |
| Processor codename |
Broadwell |
| Tcase |
74 °C |
| Maximum internal memory supported by processor |
1.54 TB |
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
1600,1866,2133 MHz |
| Memory bandwidth supported by processor (max) |
68.3 GB/s |
| ECC supported by processor |
Yes |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Maximum number of PCI Express lanes |
40 |
| Processor package size |
45 x 52.5 mm |
| Supported instruction sets |
AVX 2.0 |
| Processor code |
SR2R7 |
| Scalability |
2S |
| Physical Address Extension (PAE) |
Yes |
| Physical Address Extension (PAE) |
46 bit |
| Embedded options available |
No |
| Processor series |
Intel Xeon E5-2600 v4 |
| Conflict-Free processor |
Yes |
| Internal memory |
32 GB |
| Internal memory type |
DDR4-SDRAM |
| Maximum internal memory |
768 GB |
| Memory slots |
24 |
| ECC |
Yes |
| Memory clock speed |
2400 MHz |
| Memory layout (slots x size) |
2 x 16 GB |
| Maximum storage capacity |
96 TB |
| Total storage capacity |
0 GB |
| RAID support |
Yes |
| Optical drive type |
No |
| Number of HDDs installed |
0 |
| HDD interface |
Serial ATA, Serial Attached SCSI (SAS) |
| HDD size |
2.5″ |
| Number of HDDs supported |
8 |
| Hot-Plug support |
Yes |
| LAN controller |
HP 331i |
| Ethernet LAN |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Ethernet LAN (RJ-45) ports |
4 |
| USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| VGA (D-Sub) ports quantity |
1 |
| Serial ports quantity |
1 |
| PCI Express slots version |
3.0 |
| Chassis type |
Rack (5U) |
| Operating system installed |
No |
| Compatible operating systems |
Microsoft Windows Server
Canonical Ubuntu
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
VMware
Citrix XenServer |
| CPU configuration (max) |
2 |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
No |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel Flex Memory Access |
No |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel Enhanced Halt State |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Demand Based Switching |
Yes |
| Intel® Secure Key |
Yes |
| Intel TSX-NI |
Yes |
| Intel® OS Guard |
Yes |
| Intel 64 |
Yes |
| Intel Identity Protection Technology version |
0.00 |
| Intel Secure Key Technology version |
1.00 |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel TSX-NI version |
1.00 |
| Processor ARK ID |
92981 |
| Redundant power supply (RPS) support |
Yes |
| Power supply |
800 W |
| Number of redundant power supplies installed |
2 |
| Sustainability certificates |
ENERGY STAR |
| Width |
445 mm |
| Depth |
746 mm |
| Height |
218 mm |
| Weight |
26 kg |
| Graphics card |
G200 |
| Graphics card family |
Matrox |
