Description
The Lenovo ThinkSystem SR650 V3 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem SR650 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR650 V3 and consider its use in IT solutions.
| Feature |
Feature Value |
| Processor family |
Intel Xeon Silver |
| Processor manufacturer |
Intel |
| Processor model |
4510 |
| Processor frequency |
2.4 GHz |
| Processor boost frequency |
4.1 GHz |
| Processor cores |
12 |
| Processor cache |
30 MB |
| Number of processors installed |
1 |
| Maximum number of SMP processors |
2 |
| Internal memory |
32 GB |
| Internal memory type |
DDR5-SDRAM |
| Maximum internal memory |
8.19 TB |
| Memory slots |
32x DIMM |
| ECC |
Yes |
| Memory clock speed |
4800 MHz |
| Memory layout (slots x size) |
1 x 32 GB |
| RAID support |
Yes |
| Optical drive type |
No |
| RAID levels |
0, 1, 5, 6, 10, 50, 60 |
| Supported RAID controllers |
9350-8i |
| Hot-swap |
Yes |
| Internal drive bays |
8 |
| On-board graphics card |
Yes |
| Maximum graphics card memory |
16 MB |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| VGA (D-Sub) ports quantity |
1 |
| Chassis type |
Rack (2U) |
| Performance management |
XClarity Controller Platinum |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Compatible operating systems |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server |
| Redundant power supply (RPS) support |
Yes |
| Power supply |
1100 W |
| Power supply input frequency |
50 – 60 Hz |
| Operating temperature (T-T) |
5 – 45 °C |
| Storage temperature (T-T) |
-40 – 60 °C |
| Operating relative humidity (H-H) |
8 – 90% |
| Storage relative humidity (H-H) |
8 – 90% |
| Operating altitude |
0 – 3050 m |
| Width |
445 mm |
| Depth |
766 mm |
| Height |
87 mm |
