| Storage drives installed |
Yes |
| Total installed storage capacity |
48 TB |
| Number of storage drives installed |
8 |
| Number of storage drives supported |
8 |
| Installed storage drive type |
HDD |
| Supported storage drive types |
HDD & SSD |
| Storage drive capacity |
6 TB |
| Storage drive interface |
Serial ATA II, Serial ATA III |
| RAID support |
Yes |
| Storage drive size |
2.5/3.5″ |
| RAID levels |
0, 1, 5, 6, 10 |
| Hot-swap drive bays |
Yes |
| Supported file systems |
FAT32, HFS+, NTFS, ext3, ext4 |
| Processor frequency |
2 GHz |
| Processor cores |
4 |
| Internal memory |
4 GB |
| Internal memory type |
DDR3L |
| Maximum RAM supported |
16 GB |
| Memory slots |
2 |
| Flash memory |
512 MB |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000,10000 Mbit/s |
| Wi-Fi |
No |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Jumbo frames support |
Yes |
| iSCSI support |
Yes |
| Wake-on-LAN ready |
Yes |
| Supported network protocols |
CIFS/SMB, AFP (v3.3), NFS (v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC |
| Link aggregation |
Yes |
| Ethernet LAN (RJ-45) ports |
4 |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Fiber ports quantity |
1 |
| Fiber optic connector |
SFP+ |
| Chassis type |
Rack (2U) |
| Cooling type |
Active |
| Product colour |
Black |
| Number of fans |
2 fan(s) |
| Fan diameter |
7 cm |
| LED indicators |
HDD, LAN, Power, Status, USB |
| Type |
NAS |
| Device class |
Small & Medium Business |
| Backup function |
Yes |
| Backup features |
Cloud, iSCSI LUN |
| Buzzer |
Yes |
| Multilingual support |
Yes |
| Number of users |
4096 user(s) |
| Noise level |
36.4 dB |
| Share folder access right management |
Yes |
| Security algorithms |
256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS |
| Access Control List (ACL) |
Yes |
| Reset button |
Yes |
| On/off switch |
Yes |
| Built-in UPnP AV media server |
Yes |
| Built-in iTunes server |
Yes |
| Built-in FTP server |
Yes |
| Browser supported |
Microsoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome |
| System log |
Yes |
| Hot spare |
Yes |
| S.M.A.R.T. support |
Yes |
| Share folder |
CIFS/SMB |
| Operating system installed |
QNAP Turbo System |
| Operating system version |
4.2 |
| Windows operating systems supported |
Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 8, Windows 8 x64 |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2 |
| Power supply location |
Built-in |
| Power supply unit (PSU) capacity |
250 W |
| Number of power supply units |
1 |
| Redundant power supply (RPS) support |
Yes |
| Power consumption (typical) |
107.3 W |
| Power consumption (sleep) |
51.29 W |
| AC input voltage |
110-240 V |
| AC input frequency |
50 – 60 Hz |
| Fan voltage |
12 V |
| Output current |
5 A |
| Width |
482 mm |
| Depth |
534 mm |
| Height |
89 mm |
| Cables included |
AC, LAN (RJ-45) |
| Quick installation guide |
Yes |
| Number of screws |
56 |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
5 – 95% |
| Power management |
Yes |
| Digital Living Network Alliance (DLNA) certified |
Yes |
