Description
The purchase of a one year Logitech extended warranty along with the purchase of Rally Bar Mini adds one additional year to the original Logitech manufacturer’s two year limited hardware warranty and is intended to ensure that your Logitech hardware is free from defects in material and workmanship. This extended warranty helps to protect your investment, maximize its value, and ensure optimal performance of your Logitech conference room hardware for a total of three years. This is right in line with the typical depreciation and replacement cycle of most conference room equipment.
| Feature |
Feature Value |
| Product type |
Group video conferencing system |
| Product colour |
Graphite |
| Pan range |
-25 – 25° |
| Tilt angle range |
-15 – 15° |
| PTZ control |
Yes |
| HD type |
4K Ultra HD |
| Supported video modes |
576p, 720p, 900p, 1440p, 2160p |
| Maximum frame rate |
30 fps |
| Built-in speaker(s) |
Yes |
| Output level |
92/99 dB |
| Line-out impedance |
4 Ω |
| Output voltage Total Harmonic Distortion (THD) |
2% |
| Audio beamforming |
Yes |
| Noise reduction |
Yes |
| Echo cancellation |
Yes |
| RMS rated power |
8 W |
| Microphone pick-up range |
4.5 m |
| Sample rates |
0 – 48 kHz |
| HDMI ports quantity |
3 |
| HDMI output ports quantity |
2 |
| HDMI input ports quantity |
1 |
| USB connector type |
USB Type-A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| Ethernet LAN (RJ-45) ports |
1 |
| DC-in jack |
Yes |
| Microphone in |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Supported network protocols |
IPv4, IPv6 |
| Security algorithms |
128-bit AES |
| Zoom capability |
Yes |
| Digital zoom |
4x |
| Horizontal field of view |
113° |
| Vertical field of view |
80.7° |
| Diagonal field of view |
120° |
| Remote control interface |
Bluetooth |
| Microphone sensitivity |
-36 dB |
| Microphone frequency |
90 – 16000 Hz |
| Microphone direction type |
Omnidirectional |
| Sound pressure level (max) |
90 dB |
| Number of microphones |
6 |
| Telepresence |
No |
| Master (outer) case gross weight |
6.29 kg |
| Master (outer) case length |
804 mm |
| Master (outer) case width |
200 mm |
| Master (outer) case height |
212 mm |
| Harmonized System (HS) code |
85176990 |
| Battery capacity |
0.675 Wh |
| Windows operating systems supported |
Windows 10, Windows 11 |
| Mac operating systems supported |
Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 95% |
| Storage temperature (T-T) |
-40 – 70 °C |
| Heat dissipation |
64 BTU/h |
| Power source type |
AC |
| AC input voltage |
100 – 240 V |
| Current |
4.754 A |
| DC input voltage |
19 V |
| Battery technology |
Lithium |
| Battery capacity |
220 mAh |
| Number of batteries supported |
2 |
| Power plug type |
Type C |
| Width |
719 mm |
| Depth |
101 mm |
| Height |
91.4 mm |
| Weight |
4.03 kg |
| Package width |
191 mm |
| Package depth |
789 mm |
| Package height |
199 mm |
| Package weight |
5.8 kg |
| Cables included |
AC, DC, HDMI, USB Type-A to USB Type-C |
| Power cable length |
2.5 m |
| HDMI cable length |
2 m |
| AC adapter included |
Yes |
| Remote control included |
Yes |
| Quick start guide |
Yes |
| Packaging content |
Rally Bar Mini
Power supply
AC power cord
HDMI cable
USB cable
Remote control
Lens caps for main lens and AI Viewfinder
User documentation |
