ATEN CE920L KVM extender Transmitter

Part No:
CE920L
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?

CE920, USB DisplayPort HDBaseT2.0 KVM Transmitter

Request info below or give us a call on 0203 617 7663
SKU: CE920L Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The ATEN CE920 USB DisplayPort HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to deliver 4K video, stereo audio, USB, Ethernet*, and RS-232 signals up to 100 meters using a single Cat6 / 2L-2910 Cat 6 cable. The HDBaseT™ 2.0 guarantees the most reliable transmission on the market as well as enables the long-reach capability that extends full HD 1080P signals up to 150 meters. With an easy cable installation supporting various signals, the CE920 is ideal for applications where convenient remote access is required – such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.

* Note: The CE920L-AT supports Ethernet function and the CE920L-ATA does not.

Feature Feature Value
Type Transmitter
Connectivity technology Wired
Maximum transfer distance 150 m
Cable types supported Cat5e, Cat6, Cat6a
Maximum digital resolution 4096 x 2160 pixels
Product colour Black
Material Metal
USB 2.0 ports quantity 1
USB data transfer rates 480 Mbit/s
LED indicators Yes
Certification RoHS
Transmitter video port type DisplayPort
Transmitter local keyboard/mouse port type USB
RJ-45 ports quantity (transmitter) 1
AC adapter output voltage 5 V
Power consumption (transmitter) (max) 3.99 W
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Transmitter width 18.2 cm
Transmitter depth 12.2 cm
Transmitter height 2.87 cm
Transmitter weight 630 g
AC adapter included Yes
Cables included DisplayPort
Manual Yes
Mounting bracket(s) included Yes

Additional information

Type

Transmitter
Maximum transfer distance

150 m
Maximum digital resolution

4096 x 2160 pixels
Material

Metal
USB data transfer rates

480 Mbit/s
Certification

RoHS
AC adapter output voltage

5 V
Operating temperature (T-T)

0 – 40 °C
Transmitter depth

12.2 cm
Transmitter weight

630 g
Cables included

DisplayPort
Mounting brackets included

Yes
Connectivity technology

Wired
Cable types supported

Cat5e, Cat6, Cat6a
Product colour

Black
USB 2.0 ports quantity

1
LED indicators

Yes
Transmitter video port type

DisplayPort
Storage temperature (T-T)

-20 – 60 °C
Transmitter width

18.2 cm
Transmitter height

2.87 cm
AC adapter included

Yes
Manual

Yes

Brand

Aten
