ATEN DVI-I Single Display KVM over IP Transmitter with Internet Access

Part No:

KE6900AIT

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

DVI-I Single Display KVM over IP Tx

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: KE6900AIT Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The KE6900AiT are high performance IP-based transmitters that, when used with receivers (e.g. KE6900AR), provide console access from a separate location. The setup allows extended access of computer systems remotely via USB consoles (USB keyboard, USB mouse, DVI monitor) over intranet and internet, enabling users to place the computer system in secure and temperature controlled environments, which maybe isolated from users’ workstation.
1x KE6900AiT DVI-I Single Display KVM over IP Transmitter with Internet Access
1x 0AD8-8012-33MG Power Adapter
1x LIN2-418K-E12G Power Cord
1x LIN5-35W1-W11G KVM Cable (DVI-D, USB, Audio; 1.8m/6ft)
1x Foot Pad Set (4 pcs.)
1x KC06-0040-200G Mounting Kit
1x User Instructions

Feature Feature Value
Type Transmitter
Connectivity technology Wired
Bandwidth 0.00006 MHz
Rack mounting Yes
Maximum digital resolution 1920 x 1200 pixels
Product colour Black
Material Metal
Plug and Play Yes
Transmitter video port type DVI-I
Transmitter local video port type VGA
Number of displays supported 1
Transmitter local keyboard/mouse port type USB
RJ-45 ports quantity (transmitter) 1
AC input voltage 12 V
Power consumption (transmitter) (max) 12 W
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 95%
Transmitter width 21.5 cm
Transmitter depth 16.3 cm
Transmitter height 4.18 cm
Transmitter weight 1.16 kg
Package width 207 mm
Package depth 414 mm
Package height 117 mm
Package weight 2.35 kg
Weight 1.74 kg
AC adapter included Yes
Manual Yes
Mounting bracket(s) included Yes
USB port type USB Type-A
RS-232 ports 1
RJ-45 ports quantity 1
Master (outer) case net weight 5.22 kg
Harmonized System (HS) code 84733080
Master (outer) case width 370 mm
Master (outer) case length 427 mm
Master (outer) case height 232 mm
Master (outer) case gross weight 7.27 kg
Products per master (outer) case 3 pc(s)

Additional information

Type

Transmitter
Bandwidth

0.00006 MHz
Maximum digital resolution

1920 x 1200 pixels
Material

Metal
Transmitter video port type

DVI-I
Storage temperature (T-T)

-20 – 60 °C
Transmitter width

21.5 cm
Transmitter height

4.18 cm
Package width

207 mm
Package height

117 mm
Weight

1.74 kg
Manual

Yes
USB port type

USB Type-A
RJ-45 ports quantity

1
Harmonized System (HS) code

84733080
Master (outer) case length

427 mm
Connectivity technology

Wired
Rack mounting

Yes
Product colour

Black
Plug and Play

Yes
AC input voltage

12 V
Operating temperature (T-T)

0 – 50 °C
Transmitter depth

16.3 cm
Transmitter weight

1.16 kg
Package depth

414 mm
Package weight

2.35 kg
AC adapter included

Yes
Mounting brackets included

Yes
RS-232 ports

1
Master (outer) case width

370 mm
Master (outer) case height

232 mm

Brand

Aten
