Fortinet Switch PoE FS-124F-POE 24-port gigabit switching

Part No:

FS-124F-POE

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£1,240.93
£1,489.12
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

Available with lead time

Fortinet Switch 124F PoE – FS-124F-POE
Fortinet FS-124F-POE provides 24-port gigabit switching with Power over Ethernet support, ideal for powering connected IP devices and access points.

99999 in stock (can be backordered)

Non-Returnable*

Safe & Secure shopping

We will contact you with full lead times for this item.

*This item is non-returnable and non-cancellable due to customisation or built to order.

SKU: FS-124F-POE Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Fortinet Hardware Firewalls

Related products

Description

642528

Feature Feature Value
Basic switching RJ-45 Ethernet ports quantity 12
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Fiber ports quantity 4
Fiber optic connector SFP+
Console port RJ-45
Networking standards IEEE 802.3af, IEEE 802.3at
10G support Yes
Link aggregation Yes
Spanning tree protocol Yes
VLAN support Yes
Number of VLANs 4000
MAC address table 32000 entries
Switching capacity 128 Gbit/s
Forwarding rate 190 Mpps
Latency (1 Gbps) 1 µs
Packet buffer memory 2 MB
Access Control List (ACL) Yes
Rack mounting Yes
Form factor 1U
Product colour White
Certification FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2
Memory type DDR3-SDRAM
Internal memory 512 MB
Flash memory 64 MB
Power supply included Yes
AC input voltage 100 – 240 V
AC input frequency 50 – 60 Hz
Power consumption (typical) 235.9 W
Power consumption (max) 237.4 W
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 12
Total Power over Ethernet (PoE) budget 185 W
Operating temperature (T-T) 0 – 45 °C
Storage temperature (T-T) -20 – 70 °C
Operating relative humidity (H-H) 10 – 90%
Heat dissipation 102.982 BTU/h
Width 440 mm
Depth 260 mm
Height 44 mm
Weight 3.56 kg

Additional information

Fiber ports quantity

4
Console port

RJ-45
10G support

Yes
Spanning tree protocol

Yes
Number of VLANs

4000
Switching capacity

128 Gbit/s
Latency (1 Gbps)

1 µs
Access Control List (ACL)

Yes
Form factor

1U
Certification

FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2
Internal memory

512 MB
Power supply included

Yes
AC input frequency

50/60 Hz
Power consumption (max)

237.4 W
Operating temperature (T-T)

0 – 45 °C
Width

440 mm
Height

44 mm
Fiber optic connector

SFP+
Networking standards

IEEE 802.3af, IEEE 802.3at
Link aggregation

Yes
VLAN support

Yes
MAC address table

32000 entries
Forwarding rate

190 Mpps
Packet buffer memory

2 MB
Rack mounting

Yes
Product colour

White
Memory type

DDR3-SDRAM
Flash memory

64 MB
AC input voltage

100 – 240 V
Power consumption (typical)

235.9 W
Power over Ethernet (PoE)

Yes
Storage temperature (T-T)

-20 – 70 °C
Heat dissipation

102.982 BTU/h
Depth

260 mm
Weight

3.56 kg

Brand

Fortinet
