ATEN VE8900R AV extender AV receiver Black
Lock Added: N/A
1 in stock.
HDMI Over IP Receiver
Non-Returnable*
Related products
Description
The ATEN VE8900R Video over IP Receiver delivers visually lossless 1080p AV signals with low latency over long distance via a local network of standard Gigabit network switch*.
The VE8900R provides an effective, easy-to-use, and economical digital signage solution with the following features and advantages that directly address the challenges system integrators encounter when implementing AV over IP systems:
Engineered to meet today’s demands of large scale, multi-display, 1080p signal transmission, and designed to be easy to set up and operate, the VE8900R Video over IP Receiver is an ideal product for a wide range of environments, such as trade shows, airports, university campuses, conference centers, and shopping centers
*Note: Regarding the detail information requirement of network switch, please refer to Implementation guide: assets.aten.com/product/manual/Implementation_Guide.pdf
| Feature | Feature Value |
|---|---|
| Type | AV receiver |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 100 m |
| Audio system | stereo |
| LED indicators | Yes |
| Supported video modes | 1080p |
| HDCP | Yes |
| Material | Metal |
| Control type | Buttons |
| Baud rate | 19.2 Kbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Impedance | 100 Ω |
| Daisy chain | Yes |
| Product colour | Black |
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| Number of HDMI outputs | 1 |
| USB ports quantity | 2 |
| USB version | 2.0 |
| Video out | 1 |
| Audio output | 1 |
| Serial ports quantity | 1 |
| Serial interface type | RS-232 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
| Power consumption (typical) | 4.28 W |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating relative humidity (H-H) | 0 – 80% |
| Width | 136 mm |
| Depth | 101 mm |
| Height | 29.6 mm |
| Weight | 490 g |
| AC adapter included | Yes |
| Manual | Yes |
| Sustainability certificates | RoHS |
Additional information
| Type | AV receiver |
|---|---|
| Maximum transfer distance | 100 m |
| LED indicators | Yes |
| HDCP | Yes |
| Control type | Buttons |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Daisy chain | Yes |
| Connectivity technology | Wired |
| Number of HDMI outputs | 1 |
| USB version | 2.0 |
| Audio output | 1 |
| Serial interface type | RS-232 |
| DC-in jack | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
| Depth | 101 mm |
| Weight | 490 g |
| Manual | Yes |
| Cable types supported | Cat5e, Cat6 |
| Audio system | Stereo |
| Supported video modes | 1080p |
| Material | Metal |
| Baud rate | 19.2 Kbit/s |
| Impedance | 100 Ω |
| Product colour | Black |
| RJ-45 input ports | 1 |
| USB ports quantity | 2 |
| Video out | 1 |
| Serial ports quantity | 1 |
| Remote (IR) output | 1 |
| Power consumption (typical) | 4.28 W |
| Storage temperature (T-T) | -20 – 60 °C |
| Width | 136 mm |
| Height | 29.6 mm |
| AC adapter included | Yes |
| Sustainability certificates | RoHS |
