| Processor family |
Intel Core Ultra 5 |
| Processor cores |
10 |
| Processor socket |
FCLGA1851 |
| Box |
No |
| Processor manufacturer |
Intel |
| Processor model |
225 |
| Processor operating modes |
64-bit |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor threads |
10 |
| Performance cores |
6 |
| Efficient cores |
4 |
| Processor boost frequency |
4.9 GHz |
| Performance-core boost frequency |
4.9 GHz |
| Performance-core base frequency |
3.3 GHz |
| Efficient-core boost frequency |
4.4 GHz |
| Efficient-core base frequency |
2.7 GHz |
| Processor cache |
20 MB |
| Processor cache type |
Smart Cache |
| Processor base power |
65 W |
| Maximum turbo power |
121 W |
| AI software frameworks supported by CPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Maximum number of DMI lanes |
8 |
| Processor codename |
Arrow Lake |
| Processor ARK ID |
241070 |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
23 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
4 TOPs |
| Memory channels |
Dual-channel |
| Maximum internal memory supported by processor |
192 GB |
| Memory types supported by processor |
DDR5-SDRAM |
| Memory clock speeds supported by processor |
6400 MHz |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| On-board graphics card model |
Intel Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card outputs supported |
HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1 |
| On-board graphics card base frequency |
300 MHz |
| On-board graphics card dynamic frequency (max) |
1800 MHz |
| Number of displays supported (on-board graphics) |
4 |
| On-board graphics card DirectX version |
12.0 |
| On-board graphics card OpenGL version |
4.5 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) |
60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) |
60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) |
60 Hz |
| On-board graphics card ID |
0x7D67 |
| Xe-cores |
2 |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Market segment |
Desktop |
| Use conditions |
PC/Client/Tablet |
| Maximum number of PCI Express lanes |
24 |
| PCI Express slots version |
4.0, 5.0 |
| Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
| Scalability |
1S |
| Embedded options available |
Yes |
| Direct Media Interface (DMI) Revision |
4.0 |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Intel® Thunderbolt 4 |
Yes |
| Intel® Control-flow Enforcement Technology (CET) |
Yes |
| Intel® Thread Director |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel® Secure Key |
Yes |
| Intel® OS Guard |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® Boot Guard |
Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
| Intel® Volume Management Device (VMD) |
Yes |
| Mode-based Execute Control (MBE) |
Yes |
| Intel® Standard Manageability (ISM) |
Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on GPU |
Yes |
| Maximum operating temperature |
105 °C |
| OpenCL version |
3.0 |
| L2 cache |
22528 KB |
| Maximum internal memory |
192 GB |
| Launch date |
Q1’25 |
| Status |
Launched |
| Graphics output |
DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b |
